Process flow diagram of zirconium titanium sand ore gravity separation

Zirconium titanium placer is an important metal mineral resource widely used in aviation, aerospace, military industry, chemical industry, electronics, building materials and other fields. Due to the high content of impurities in zirconium titanium sand ore, gravity separation is necessary. This article will introduce the process flow chart and operating steps of zirconium titanium sand ore gravity separation for everyone.

1. Zirconium titanium sand ore gravity separation process flowchart

The process flow diagram of zirconium titanium sand ore gravity separation is as follows:

1. Grinding: Crushing and grinding zirconium titanium sand ore for better gravity separation.

2. Coarse separation: Using the heavy medium separation method, the zirconium titanium sand ore is divided into two parts: heavy ore and light ore.

3. Medium separation: heavy ore is divided into zircon and Ilmenite by heavy medium separation method.

4. Cleaning: Zircon and Ilmenite are separated by electric separation.

5. Tailings treatment: The tailings generated during the selection process are treated to reduce their impact on the environment.

2、 Operating Steps

1. Grinding: Zirconium titanium sand ore is crushed and finely ground, usually using a ball mill for grinding. The purpose of grinding is to finely grind zirconium titanium sand ore for better gravity separation.

2. Rough selection: The finely ground zirconium titanium sand ore is subjected to heavy medium separation, usually using a heavy liquid flotation machine for rough selection. The principle of heavy medium separation is to use the density difference of different minerals to divide the zircon titanium placer into heavy ore and light ore.

3. Intermediate separation: The heavy ore is separated by a heavy medium, usually using a heavy liquid flotation machine for intermediate separation. The purpose of the concentration is to divide the heavy ore into zircon and Ilmenite.

4. Cleaning: Zircon and Ilmenite are separated by electric separation, generally using high-voltage electrostatic separator for cleaning. The principle of electric separation is to separate zircon from Ilmenite by using the difference of conductivity of different minerals.

5. Tailings treatment: The tailings generated during the selection process are treated, usually using a flotation machine for tailings treatment. The purpose of tailings treatment is to reduce its impact on the environment.

3、 Summary

The process flow diagram of zirconium titanium sand ore gravity separation is an important reference in the process of zirconium titanium sand ore gravity separation. Through steps such as grinding, rough selection, intermediate selection, selection, and tailings treatment, impurities in zirconium titanium placer can be separated to obtain high-quality zirconium titanium placer products. During the operation process, attention should be paid to the selection and maintenance of equipment to ensure production efficiency and product quality.
